| 項目 | GCL-5F21E 仕様 |
|---|---|
| ブランド | iRAYPLE |
| シリーズ | CameraLink |
| 型式 | GCL-5F21E |
| カメラインターフェース | CameraLink |
| ポート数 | 2ch |
| コネクタ形状 | SDR |
| カメラ接続可能台数 | Medium/Full/Deca 2台 |
| ホストインターフェイス | PCIe x4 (Gen2) |
| 最大データ転送速度 | 1650 MB/s |
| Power over対応 | PoCL対応 |
| オンボードメモリ | 1GB |
| GPIO | "入力：①差動×2, ②シングルエンド×4 出力：シングルエンド×4" |
| 拡張IO（TTL,Opto入力ボード使用時） | - |
| 寸法(L x H) | 151.6mm×126.3mm×21.6mm |
| 適用温度保管時 | -20~70℃ |
| 適用温度動作時 | 0~50℃ |
| 準拠規格 | TBA |
