| 項目 | GX3-6D41E 仕様 |
|---|---|
| ブランド | iRAYPLE |
| シリーズ | CoaXPress-6 |
| 型式 | GX3-6D41E |
| カメラインターフェース | CXP-6 |
| ポート数 | 4ch |
| コネクタ形状 | DIN 1.0/2.3 |
| カメラ接続可能台数 | CXP-6 4台 |
| ホストインターフェイス | PCIe x4 (Gen3) |
| 最大データ転送速度 | 3300MB/s |
| Power over対応 | PoCXP対応 |
| オンボードメモリ | 1GB |
| GPIO | 差動入力×8, 差動出力×3, 汎用入出力(TTL)×2 |
| 拡張IO（TTL,Opto入力ボード使用時） | - |
| 寸法(L x H) | 144.8mm × 104.9mm |
| 適用温度保管時 | -15~85℃ |
| 適用温度動作時 | 0~60℃ |
| 準拠規格 | TBA |
